8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet

Product Categories

CNC Fiber Laser Cutting Machine [533]
CNC Laser Cutting Machine [62]
Sheet Laser Cutting Machine [26]
Metal Laser Cutting Machine [28]
Plate Fiber Laser Cutting Machine [32]
Tube Fiber Laser Cutting Machine [32]
Tube Laser Cutting Machine [20]
High Power Fiber Laser Cutting Machine [28]
Laser Welding Machine [28]
Portable Plasma Cutting Machine [30]
Heavy Duty Plasma Cutting Machine [32]
Gantry Plasma Cutting Machine [20]
Tube Plasma Cutting Machine [20]
Plasma And Flame Cutting Machine [22]
Vertical CNC Milling Machine [68]

Shandong Honest Machinery Co., Ltd.

Contact Now

8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet

Name: 8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet
Brand: Honest
Price: 16800 USD

Quality 8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet wholesale

Brand Name : Honest

Model Number : 4020

Certification : CE ISO

Place of Origin : China

MOQ : 1

Price : 16800$-30000$ per one set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Trade Assurance

Supply Ability : 20 per a month

Delivery Time : 10-20 wooking days

Packaging Details : wooden package

Cutting thickness : Materials

Control software : Cypcut

Application : Laser Cutting

Cooling mode : Water Cooling

Cutting speed : 120/min

Control system : Cypcut

After-sales service provided : Engineers available to service machinery overseas

Laser source : Raycus or IPG or Max

Contact Now

8000w Fiber Laser Cutting Machines 6020 Cnc Laser Cutting Machine For Metal Sheet

Why more and more enterprises choose advanced fiber laser cutting machine? In the continuous development of science and technology today, only continuous progress, follow the development of The Times, can effectively occupy the leading position in the market. First of all, we all know that the fiber laser cutting machine has high precision, fast speed and narrow slit, so the cut surface is smooth without burr; Secondly, because the slit is very narrow, the heat affected zone is small, and the metal material surface is not in direct contact, so the workpiece will rarely appear mechanical deformation. Therefore, the use of fiber laser cutting machine is more and more extensive, the application effect is remarkable. Stainless steel, carbon steel, aluminum, galvanized sheet, iron and other metal materials can be fast, accurate, high efficiency cutting.

Product Advantages

More than a decade to provide industry worldwide high quality series laser cutting equipment and perfect technical service, engineering machinery, automobile, machine tools, ships, locomotives, petroleum machinery, aerospace, military industry, agricultural machinery, textile machinery, food machine, electrical appliances, elevators, and other application fields, are sold to more than 80 countries around the world, there have been thousands of laser cutting equipment in good running all over the world.

8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet

product details

Special fiber cutting head German craftsmanship, technology is stable and reliable; the internal structure of the laser head is complete Fully sealed, can prevent the optical part from being polluted by dust. Laser head mining Two-point centering adjustment is used, and the focusing is driven by an imported motor. Surface efficiency is significantly improved; the protective lens adopts drawer type installation and replacement convenient.

Bed part

Aero-aluminum Integrated Beam
 * High precision. After manual aging, solution treatment and finishing, the beam has good integrity, rigidity, toughness and
 ductility.


Beam Section

The beam adopts aluminum structure, which greatly improves the stability of the machine tool. It adopts heavy-duty steel mold pressure casting; the mold cost is high but the life is long, and the aluminum water has good fluidity and uniform density. High strength; elimination of casting defects such as blisters; good surface roughness, no

Smart operating system

CypCut professional intelligent control system, with automatic nesting function, stable performance, fast operation, supports multiple common file formats, DXF, PL...concise and fast operating system, -key import of multiple types of cutting graphics, accurate cutting instructions, Make the user experience bette

Technique Parameters

Feature/Model	HN3015	HN4015	HN4020
Working Area (L*W))	3000mm*1500mm	4000mm*1500mm	4000mm*2000mm
Stroke (X/ Y/ Z Axis)	1525mm/3025mm/150mm	1525mm/4025mm/150mm	2025mm/4025mm/150mm
X/Y Axis Positioning Accuracy	±0.03mm/m	±0.03mm/m	±0.03mm/m
X/Y Axis Repositioning Accuracy	±0.03mm	±0.03mm	±0.03mm
Max. Moving Speed	110m/min	110m/min	110m/min
Max. Acc. Speed	1.0G	1.0G	1.0G
Power Porection Grade	IP54	IP54	IP54
Laser Power	1500W~4000W	1500W~4000W	1500W~4000W
Max. Loading Weight	800kg	1000kg	1400kg
Machine Weight	3300Kg	4000Kg	5100Kg
Overall Dimensions (LWH)	4850X2730X1700mm	6015X2730X1700mm	6015X3300X1700mm

Application Example

Fiber laser cutting machine is used in sheet metal processing, advertising sign production, cabinet electrical cabinets,mechanical
 parts, kitchenware, sanitary ware, auto parts, machinery manufacturing,metal crafts, saw blades, electrical parts,glasses
 industry, spring sheets, circuit boards,electrical Kettles, medical microelectronics, hardware, doors and windows and other
 industries.

Packaging＆Shipping

1. Outside package: Standard marine export plywood case.2. Inner package: Stretchy film and plastic film for humidity. We can
 package according to your requests. Delivery Detail: Shipped in 15-30 working days after payment.

8kw CNC Fiber Laser Cutting Machine

Metal Sheet 8000w Laser Cutting Machine

Cnc 8000w Fiber Laser Cutting Machine

8000w Fiber Laser Cutting Machine 6020 Cnc For Metal Sheet Images
